Fully automatic n95 / kn95 mask machine equipment for production medical mask

Ask Lasest Price
Brand Name :	YBT
Model Number :	N95 Face mask making machine
Certification :	CE FDA
Price :	Negotiation
Payment Terms :	T/T
Supply Ability :	10set
Delivery Time :	7-15 days

Add to Cart

Product Details
Company Profile

Fully automatic n95 / kn95 mask machine equipment for production medical mask

Fully automatic n95 / kn95 mask machine equipment for production medical mask

Product Description

Automatic kn95 surgical mask making machine,full line include one
mask blank machine, one ear loop welding machine,one edge banding
machine,one nose clip machine

Dimension	8000mm(L) X1400mm(W) X1600mm(H)
Color	International standard warm grey 1C
Weight	≤3000kg, ground weight capacity≤500kg/m2 ≤5000kg, ground weight capacity ≤500kg/m2
Working power	equipment 220VAC±5%; 50HZ;rated power 17KW
Working air pressure	Compressed air pressure 0.5-0.8MPa; compressed air flux 300L/min(stable flux guaranteed; oil and water have to be filtered)
Production efficiency	1800-2500PCS/H(based on 20 hours each day, daily capacity about 36,000-50,000 pieces)
Qualification ratio	99%(excluding unqualified incoming materials, improper operation by employees)
Equip failure ratio	≤2%(equipment failure itself)
Operating environment	Temperature 10~35℃; humidity: 5-35%HR No flammable, corrosive gas, no dust (cleanliness no less than 100,000 grade)
Raw Material Recommendation	Cloth:(meltblown nonwoven, PPnonwoven)

Technical characteristics

The top layer, filter layer, and bottom layer of three rolls of fabric are automatically aligned and fed.The two sides are continuously rolled by the ultrasonic system.The nose clip is automatically cut & fed into the underlying fabric, and the first step of pressing and merging is cut into a single fabric at the same time;
After the lamination is completed, the conveying line is sent into two automatic welding ear belt devices in a one-to-two manner;
The earband is automatically welded through automatic cutting, clamping, handling and positioning, and ultrasonic welding.
After the welding, the mask will automatically goes to the next process.
The machine is made of aluminum alloy which makes it beautiful, prevented from rust and has a small size.
The machine can make the 1--4 levels mask blank according for the customer's require with a high output;
You can adjust the size of the mask blank and the folding location;
The direction of the ear loop is outside;
Compared with sub-mask production equipment, this set of equipment more efficient, more economical artificial;
The computer program control and photoelectric detection make it have a high reliability and low failure rate.
