Disposable nonwoven medical face mask making machine, mask
production line
Product Description
This production line is a fully automatic one-to-two face mask
machine, one body machine drives two ear band machines. After the
main body machine outputs the mask body, the mask body sheet is
conveyed to the turning mechanism by a conveyor belt structure. The
reversing mechanism is used to flip the mask plate onto the belt
connected to the ear band machine, and then the mask sheet is
conveyed to the first mask plate on the front of the ear band
machine through the conveyor belt, and finally the mask sheet is
placed on the ear band by the cylinder pressing In the mask plate
of the machine, the ear band machine is used to complete the
welding of the ear bands of the mask and the edging, thereby
completing the production of an ear band mask product.
Technical Parameters
Technology | 1 Set body + 2 Welding line |
Voltage | 220V, 50/60 HZ, IP |
Power | 9KW |
Weight | 3000-5000KG |
Dimension (L*W*H) | 6500*5000*2000MM |
Mask Size | 175*95mm |
For kids mask, size is150*90mm, if you need the machines to produce
different sizes, you will need to buy the mould |
Production speed | 100-120pcs / minute |
Drive Engine | TECO Servo Motor 4 Sets |
Welding wheel | DC53 Steel |
Cutter wheel | DC53 Steel |
Ear knife blade | High-speed Steel Material |
Electrical control | Mitsubishi |
Warranty Time | 1 Year |
After sales Service | Lifelong |
Machine function
[1]. Using ultrasonic vibration&special flower wheel, after
pressurizing, achieve the desired effect.
[2]. During processing, it does not emit smoke, sparks, does not
harm the edges of the cloth, and can avoid burrs.
[3]. The flower wheel can be changed according to the customer's
needs.
[4]. It can be manufactured continuously without preheating.
[5]. It can adjust the equipment to obtain the mask width, nose
bridge line, and ear-loop length required by the customer.
Machine Introduction
This machine is three machine combine together: Mask blank machine,
Connection machine and Ear-loop welding machine. Using the
advantage PLC control all the machines. This machine from the raw
materials, mask body making,auto sent to ear-loop machine, ear-loop
welding, mask finished all production line automatic complete
finished.
[1]. Mask blank machine: Feeder, Rack (Working table and mask),
Nose wire insert,Edge sealing, Plaiting, Cutting andFinishing
products, Power transmission system, Ultrasonic generator,
Ultrasonic transducer, Electrical control.
[2]. Connection machine: Mounting plate, Transmission system.
[3]. Ear-loop welding machine: Rack(Working table), Power
transmission system,
Transmission system, Conveyor belt , Ear-loop welding, Ultrasonic
generator,
