    Fireproof Sheet Roller Shutter Door Making Machine , Door Panel Roll Forming Machine Custom Color

    Ask Lasest Price
    Brand Name : YBT
    Model Number : YT233121
    Certification : CE ISO SGS
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 10 sets per month
    Delivery Time : 45-60 days
    • Product Details
    • Company Profile

    Fireproof Sheet Roller Shutter Door Making Machine , Door Panel Roll Forming Machine Custom Color

    PLC Control fireproof sheet roller shutter door roll forming machine equipment


    Description:


    The machine works stably and no noise. In addition, it's easy to control and operate. Our machines are welcomed by global customers for high precision, especially in Russia, middle east and China. We can customize machines according to customer's requirements and offer free after-sale service. This product is very popuar and widely used in family structure, building structure, shopping mall, office etc.


    Echnical parameters

    Namemetal steel fireproof roller shutter door frame cold making production line/Slide shutter door machine
    Suitable to processColor steel plate, galvanized sheet, aluminum coils and etc.
    Width of the feeding material100-160mm
    Roller station10-15 rows
    Thickness of feeding material0.3-1.2mm
    Power Supply380V, 3-Phase,50Hz
    Productivity10-20m/min
    Rollers' material45# steel
    Diameter of shaft75mm
    Roller Diameter50mm
    Wall thickness of main forming machine14mm steel plate
    Main forming machine body300 mm H steel
    Motor power4+3kw
    Cutter StandardGCr12
    Size7500*1500*1600mm
    WeightAbout 2.5T
    Custom
    According to customer's requirements

    Machine components:

    1Decoiler1 set
    2Guide Feeding device1 set
    3main forming machine1 set
    4Foaming machine (just foamed one owned)1 set
    5Straighten device1 set
    6Punching device1 set
    7flying saw cutting machine1 set
    8finished products table1 set
    9PLC control system PLC1 set
    10Spare Parts And Tools1 set


    Packaging & Shipping

    1. Main body of Shutter Door Frame Roll Forming Machine is naked and covered by plastic film(to protect of dust and corrosion),loaded into container and steadily fixed in 1x40GP container with steel rope and lock catch suitable for long-distance transportation,

    2. spare parts are covered by plastic film.

    3. With even lifting point in the machine for easy container loading and uploading.

    Our Services

    Warranty:

    1 year warranty, we also will supply technical and fittings after warranty


    After-services:

    if you come to our factory examine goods, we will teach you how to control machine until completed control it
