    PLC Automatic Control Shutter Door Roll Forming Machine Working Radius ≤500mm

    Ask Lasest Price
    Brand Name : YBT
    Model Number : YB981703
    Certification : CE ISO SGS
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 10set
    Delivery Time : 45-60 days
    • Product Details
    • Company Profile

    PLC Automatic Control Shutter Door Roll Forming Machine Working Radius ≤500mm

    PLC automatic control system high speed roller shutter door spiral orbit machine


    Description


    European type shutter door is a type of shutter door, with multiple joint movement of the door piece in series together, in the fixed slide, with the door above the scroll as the center of the door rotation up and down.This door is generally installed in the place where the wall separation is inconvenient. It is suitable for commercial facade, garages, shopping malls, hospitals, factories and mining enterprises and other public places or residential buildings.



    Main Machine Technical Specifications

    Product nameHigh speed metal door forming machine
    Suitable plate of the bending

    Aluminum alloy


    Working speed2-3 sets/min
    Roller materialCR12, HRC 60 Degree. roller diameter φ120
    Material of principal axisFine steel modulation processing of 45(axis diameter:φ50)
    Sprocket wheel45 steel high-frequencies quench
    Motor power2.2 KW 380V 50HZ 3Phase
    Lifting synchronous motor1.5KW Servo motor
    Working radius≤500mm
    Produce products radius

    Through the PLC control


    Overall Dimension500mmX500mmX1200mm
    Total weight0.8 ton approximately

    Advantage:

    1. The machine is our new type new design,use all import electric part such as PLC,Frequency converter,

    2. The electromagnetic valve,Aviation plug,Touch screen,and so on.we use the brand such Mitsubishi,Matsushita,Siemens and so on

    3. Also the oil pump,electric motor Reducer we use Yuken, all the part of the machine have best quality and more than 35 years life time.

    4. The production size we can design the machine all as customize,customer just show us the profile drawing material thickness width, we can design the machine according as the request

    5. When we finish the machine, we will test the machine and adjust the machine many times to be sure the machine have a perfect status

    6. when customer receive the machine, the machine can be used very easy


    FAQ

    Are you a manufacturer?
    Yes, we are a leading roll forming machine manufacturer with design branches based in Italy, Russia and Taiwan.

    What's your warranty ?
    1 years warranty for the whole machine and 10 years warranty for rollers from the date of installation.

    What's your delivery time ?
    Within 45-60 days after receiving prepaid. Some machines are in stock, so can be delivered at any time.

    What's your payment terms ?
    30% deposit is paid before production, the balance should be paid after inspection confirmation and before shipment.

    How does your factory do with quality control?
    The quality control of our machines conforms to CE and ISO 9001 standards.
    Each machine will be tested before packing and shipping.

    Do you sell standardized machines?
    Most of our machines are customized, We design machines according to customer needs .

    What's your install and training ?
    If buyers come to our factory to inspect, the training to install and operate is provided face to face.
    If not, manual and video is provided to show how to install and operate.

    What's your after-sale service ?
    We provide 24-hour online service for our customers.
