Protection Fence Highway Safety Guardrail Roll Forming Machine
This is gearbox transmission highway guardrail roll forming
machine, very popular in Algeria, Asia, Europ, America, South
America. The machine can use material thickness range is up to
3.0mm, gear box transmission, the structure frame of the machine we
adopt new type whole piece cast iron, double bearing will make the
machine working more smoothly.
About order ?
What information you need to prepare the quotation ?
coil thickness(min-max)? coil width(min-max)? what is your steel
material ?
weight of your coils(max)? how many pieces need to slit for max
thickness? how many tons you need per day or per month?
Technical Parameters:
| No. | Item | Spec |
| 1 | Can Formed Material | PPGI,GI,Carbon steel |
| 2 | Equipment operation | Automatic |
| 3 | Voltage | 380V 60Hz 3Phase or as your requirement |
| 4 | Thickness of sheet (mm) | 1.5-3.0mm |
| 5 | Material width(mm) | As your requirement |
| 6 | Cover Width of the sheet after formed | as your drawing |
| 7 | The size of the roll forming machine | 10000mmx1800mmx1400mm |
| 8 | Speed | 3-5m/min |
| 9 | Diameter of shaft | 110mm |
| 10 | Weight of the Machine | 10000-12000KGS |
| 11 | Material of rollers | C45 steel quenched and chromed |
| 12 | Motor brand | Siemens |
| 13 | PLC | Siemens or Delta or Mitsubushi |
| 14 | Total power (kw) | 39.5kw |
| 15 | Power of hydraulic system | 7.5kw |
Components for the Machine:
This highway guardrail roll forming machine line include 5 ton
manual decoiler, leveling station, pre-punch die- roll forming
station, PLC control system, hydraulic cutting system and run out
table.
Forming section
Shaft diameter: diameter110 mm material: SAE1045 with quenching and
tempering
Forming station: about 16 stations (according the final design)
Machine roll forming speed: 0m-15m/min(without punching)
Machine Voltage, Frequency: Japan Yaskawa(380 V, 50 Hz, 3Phase) |
Material of rollers: 45# steel, roller surfaces polishing, hard
plating. The polished surface and the heat treatment towards the
molds also can keep the molding. Plate surface smooth and not easy
to be marked when it is being stamped
Drawing of Highway Guardrail Metal Automatic Roll Forming Machine
Package
1) . Container packing of the line suitable for overseas shipping
2) . The subjects can be loaded in one 20’ container.
3) . Package style: Covered by plastic film, spare parts and some
small parts packed in carton box.
