Floor deck panel roll forming machine 16 rolling steps 8 - 12m / min

Our machine has high grade quality and reasonable price.It also has high efficiency. We have good reputation all over the world. They are welcomed by customers around the world, And our company can customize special type,the quality can be guaranteed because we provide free after-sale service.

Machine information:

Raw material can be galvanized/aluminum/color steel sheet

Width of plate:1250mm

Thickness of plate:0.3-0.8mm

Rollers are high grade 45# steel with hard chrome plating

Shaft material: high grade 45# steel, 75mm diemeter with heat treatment

Working speed can reach 8-12m/min

Control system : Taida brand PLC control

Cutting head Cr12 mould steel with quenched treatment

Other details:

1. Color:Blue, We can make and design as customer's requiement.

2. Control System:PLC Computer

3. Effective Width:840/900mm

4. Coil Width:1250mm

5. Sheet Thickness:0.3-0.8mm

6. Pump Power:3kw

7. Main Moter Power:5.5kw

8. Middle Plate:14mm

9. Chain:1 Inch

Service Commitment & Quality Assurance:
Installation: If necessary, engineer is available to service machinery

overseas; but all the relevant cost and extra 100USD/day for our

engineer will be paid by the buyer.

Warranty: 1 year since the machine leave seller's factory.
During the warranty period, it covers all spare parts of machines, if

you find some spare parts were damaged, those new spare parts will be

supplied free by us, but normal wear and tear excepted. And the

freight should be bore equally by both parties.

Wuxi YBT machinery Equipment co.,ltd established in 1998, specialize in cold roll forming machine and auto-producing line.To put customers'benefit on the first, we know our success comes from customers'success and support. We run this mind through the whole process from the design and develpment to after-sale service in order to help our customer increase efficiency and reduce cost to strengthen competitive forces. Our designer and sales will listen to your reuirement to help you receive an ideal equipment.Our company has perfect internte for after-sale service which can support the after-sales so that you can get the satisfied equipment, ensure you receive our considerate service by solving all the problems which appeared during using the machine.
We will do the best machine to my all customers!

Our roll forming machine series:

1. Steel Silo Roll Forming Machine

2. Shutter Door Roll Forming Machine

3. C Z Purlin Roll Forming Machine

4. PU Sandwich Panel Line

5. Rock Wool Production Line

6. Highway Guardrail Roll Forming Machine

7. Floor Deck Roll Forming Machine

8. Cable Tray Roll Forming Machine

9. Steel Roll Forming Machine

10. Metal Slitting Line

11. Cut To Length Line Machine

12. Downpipe Roll Forming Machine

13. H Beam Welding Line

We will try do our best for make best quality machine!
